Replace Donaldson Air Filter Cartridge
Air filter cartridge Why should you choose R.H. air filter cartridge?1.We are the distributer of HV and Ahlstrom . ensure our filter material is excellence2.We have own filter cartridge testing machine, ensure our quality is excellence3.We have the most advanced pleat machine. ensure the delivery......
Send Inquiry
Product Description
Air filter cartridge
Why should you choose R.H. air filter cartridge?
1.We are the distributer of HV and Ahlstrom . ensure our filter material is excellence
2.We have own filter cartridge testing machine, ensure our quality is excellence
3.We have the most advanced pleat machine. ensure the delivery time is fast .
4.We have ISO 9001:2008
Air filter cartridge Performance Description:
A. Wider pleat width
B. High filtration efficiency
C. Filter Material: 80%Cellulose+20% Polyester
D. Excellent ability for moisture protection
E. Top open, bottom open/ bottom close with deflating bolt hole
F. Galvanized Stainless metal configuration
G. Rubber seal
H. We choose the moisture-proof material for the wet climate environment, also the material is suit for the large air flow design
I. We choose the secondary filtration model for heavy dust density in the windy sand climate environment. Shower-proof felt and pre-filtration cloth needed in the pre-filtration
Why should you choose R.H. air filter cartridge?
1.We are the distributer of HV and Ahlstrom . ensure our filter material is excellence
2.We have own filter cartridge testing machine, ensure our quality is excellence
3.We have the most advanced pleat machine. ensure the delivery time is fast .
4.We have ISO 9001:2008
Air filter cartridge Performance Description:
A. Wider pleat width
B. High filtration efficiency
C. Filter Material: 80%Cellulose+20% Polyester
D. Excellent ability for moisture protection
E. Top open, bottom open/ bottom close with deflating bolt hole
F. Galvanized Stainless metal configuration
G. Rubber seal
H. We choose the moisture-proof material for the wet climate environment, also the material is suit for the large air flow design
I. We choose the secondary filtration model for heavy dust density in the windy sand climate environment. Shower-proof felt and pre-filtration cloth needed in the pre-filtration
| Cartridge Model | Top end OD. | Bottom end OD. | Top ID. | Bolt hole(mm) | Height (mm) | Filtration area(m2) | Roted air flow(m3/h) | Initial resistance(pa) | Filtration precision |
| RH/Z3266 | 324mm | 324mm | 213 | 14 | 660 | 21 | 800 | 80~100 | 1~2μ m |
| RH/Z3275 | 324mm | 324mm | 213 | 14 | 750 | 24 | 900 | 80~100 | 1~2μ m |
| RH/Z32100 | 324mm | 324mm | 345 | 14 | 1000 | 23 | 1200 | 80~100 | 1~2μ m |
