5 Micron 20 Micron Polypropylene Water Filter Cartridges for Pre-Filter
5 Micron 20 Micron Polypropylene Water Filter Cartridges for pre-filterBrief introduction: PP melt-blown Filter is composed of polypropylene superfine fiber which melted and entangled at high temperatures.The fiber without any chemical adhesives forms three-dimensional micro porous structure whi......
Send Inquiry
Product Description
Brief introduction:
PP melt-blown Filter is composed of polypropylene superfine fiber which melted and entangled at high temperatures.
The fiber without any chemical adhesives forms three-dimensional micro porous structure which integrates the surface, the deep and the coarse filter together. Because the fiber and density in the diameter direction of the filter forms deep filtering structure with high filtration precision, high pollutant assimilative capacity, small pressure difference, dense inside and sparse outside gradient aperture structure. It has strong pollutant assimilative capacity, and can effectively remove the impurities such as suspended solids in the flow of fluid, particles, rust, etc. it also have a good filtering performance and long service life.
3. Production Features:
- The surface with deep hole groove structure can scatter the direction of flow and reduce the flow resistance
- Progressive density structure can increase the carrying capacity of the pollutant
- Reinforce the surface fiber structure and reduce the depilation possibility
- Be made of PP superfine fiber which have high filtration precision
- 100% pure PP can ensure high corrosion resistance
- shape in hot melt way without any chemical adhesive
Main Parameters:
Product Name | PP melt blown filter cartridge | |||
Length | 10" | 20" | 30" | 40" |
Flow(t/h) | 0.5 | 1 | 1.5 | 2 |
Area(m2) | 0.5 | 1 | 1.5 | 2 |
Diameter(Standard) | OD(63mm), ID(30mm) | |||
Diameter(Jumbo) | OD(115mm), ID(30mm) | |||
Material | PP | |||
Micron rating(μm) | 1, 5, 10, 25, 50, 75, 100, 150, 200 | |||
Features and Benefits:
(1)5, &10 Micron nominal filtration
(2)High chlorine taste and odor reduction-high chlorine adsorption capacity
(3)High dirt holding capacity extends service life
(4)Excellent for pre-filtration or pre-treatment in RO application
(5)Designed to be used in most standard-size housings
(6)Performance data based on manufacturer's internal testing.Not performance certified or tested by NSF
(7)Reduces Chlorine/chloramines, VOCs, pesticides and taste / odor contaminants
(8)change cartridge every 6-10 months or upon substantial pressure reduction
If you don't have the filter model ,please provide the further information as below:
1,Photo of filter
2,ID,OD,Height
3,Filtration Micron
4,Qty
Notice : please send the filter dimension ,filter photo and micron before quote
The sample can be sent directly ,please contact us now :
