Bag Filter Housing for Water Treatment Stainless Steel
Our companyYuzhou Yuwei Filter Equipment Co., Ltd. is an integrated corporation which has specialised in the development, manufacture and worldwide sale of mechanical filtration plants and dewatering systems for industrial separation processes. Our products include two series: filter press and stain......
Send Inquiry
Product Description
Our companyYuzhou Yuwei Filter Equipment Co., Ltd. is an integrated corporation which has specialised in the development, manufacture and worldwide sale of mechanical filtration plants and dewatering systems for industrial separation processes. Our products include two series: filter press and stainless steel filter. The filter press includes: plate and frame filter press, program controlled automatic chamber filter press, automatic membrane filter press,belt filter press and so on. Stainless steel filter includes high efficiency sealed plate filter,candle style filter,PA/PE micro hole filter,automatic washing filter,multiple media filter,bag filter and cartridge filter and so on. Meanwhile,we supply the quality filter plates,filter cloths,filter paper and filter membrane,filter bag,cartridge and so on.
Our strengths
Our company is professional supplier on filter press for many years. We have a professional sales team and product- developing team. Meanwhile,our after-sales team is more than 30 peoples. Our team is committed to assist you during the start-up and operation process of our equipment. We can give on-site training, we can help you with troubleshooting techniques.
The feature
Normally bag filter is used for some coarse filtration and pre-filtration process. Bag filter is divided into two types: single bag and multi-bag.
The bag filter consists of housing,supporting basket and filter bag. The filter bag is supported by the stainless steel mesh. The liquid enter into the housing from the inlet,going through the filter bag. Then the liquid is evenly filtered by the filter bag under the pressure from the pump. The impurities will be trapped in the filter bag. And the filtration process is completed. The bag can be reused and it is very easy to change.The clean removal efficiency is to <5 micron (μm).
Bag filter is widely used in chemical industry,pharmacy,automobile industry,food industry and so on.
| Model | Quantity of Bags | Filter Area(m2) | Max Flow(T/H) | Inlet/Outlet | Working Pressure(Mpa) | Housing diameter(mm) | Total Height(mm) | Housing Height(mm) |
| DL-2P2S | 2 | 1 | 70 | DN50 | 0.5 | 456 | 1572 | 1144 |
| DL-3P2S | 3 | 1.5 | 105 | DN80 | 508 | 1592 | 1190 | |
| DL-4P2S | 4 | 2 | 140 | DN100 | 558 | 1632 | 1244 | |
| DL-5P2S | 5 | 2.5 | 175 | DN150 | 608 | 1788 | 1254 | |
| DL-6P2S | 6 | 3 | 210 | DN150 | 658 | 1854 | 1300 | |
| DL-7P2S | 7 | 3.5 | 245 | DN150 | 710 | 1875 | 1340 | |
| DL-8P2S | 8 | 4 | 280 | DN150 | 760 | 1922 | 1404 | |
| DL-10P2S | 10 | 5 | 350 | DN200 | 910 | 2004 | 1430 | |
| DL-12P2S | 12 | 6 | 420 | DN200 | 962 | 2064 | 1460 | |
| DL-14P2S | 14 | 7 | 490 | DN200 | 1012 | 2124 | 1490 | |
| DL-16P2S | 16 | 8 | 560 | DN250 | 1112 | 2146 | 1512 | |
| DL-18P2S | 18 | 9 | 630 | DN250 | 1162 | 2225 | 1595 | |
| DL-20P2S | 20 | 10 | 700 | DN250 | 1212 | 2280 | 1640 | |
| DL-22P2S | 22 | 11 | 770 | DN250 | 1366 | 2320 | 1694 | |
| DL-24P2S | 24 | 12 | 840 | DN300 | 1416 | 2358 | 1748 |
FAQ
------------------------------------------------------------------------------------------------------------------------------------------------------
Q: Are you trading company or manufacture?
A: We are both manufacture and trading company. We have over 20 years' professional experience as a waste water treatment equipment manufacturer and engineering service enterprise.
Q: Do you provide OEM service?
A: Yes. Any required logos is available.
Q: How about the production capacity of your company?
A: Our factory covers area over 20,000M2 and produces machines 5000 sets per year.
Q: How could we trust you and your company? This is first time transaction?
A: Our company has more than 20 years professional experience. We cooperate over 1000 customers in China and overseas. We export nearly 40 countries all over the world. Welcome to our company and watch our plant production condition any time.
Q: Do you offer after-sales service?
A: Yes. Engineers available.
Q: How long is your warranty?
A: One year after the arrival of the goods. During this period, as long as it is not a man-made damage, we send the damaged parts free of charge.
Q: What about your delivery Time?
A: Normally within 45 days against down payment.
Q: What about the package of your export product?
A: We use anticorrosion wooden case with foam inside.
Q: What kind of payment do you accept?
A: T/T, L/C,WESTERN UNIION, MONEYGRAM
Q: What kind of transportation do you offer?
A: Customers decide freight mode, Air, Land & Sea .
