Cleaning and Disinfection Single-Stage Pure Water Machine Water Purifier for Hospital Supply Room
AdvantagesThe pure water machine in the disinfection supply center fully meets the requirements of water quality, the touch screen is fully automatic controlled, and the medical pure water machine can be remotely operated by computer or mobile phone.USAGE ENVIRONMENT OF MEDICAL PURE WATER MACHINEWat......
Send Inquiry
Product Description
Advantages
The pure water machine in the disinfection supply center fully meets the requirements of water quality, the touch screen is fully automatic controlled, and the medical pure water machine can be remotely operated by computer or mobile phone.
USAGE ENVIRONMENT OF MEDICAL PURE WATER MACHINE
Water quality in accordance with gb5749-2006 calibration water pressure 0.2-0.4mpa, Power source: 380V/50Hz three-phase five-wire system, reliable grounding environmental
temperature: 5-35ºC,Environmental degree: ≤ 80% RH, Installation site: the ground is flat and waterproof, with smooth drainage floor drain or drainage trench, no direct sunlight
Technical participation of medical pure water machine
The water quality of the water meets the requirements of the management standard of Hospital Disinfection Supply
Center (WS310.1-2016). Ion
removal rate: ≥99%, bacterial virus removal
rate: ≥99%, recovery rate: ≥60%
Features of medical pure water machine
· The quality of produced water shall comply with WS310.1-2016 Management Standard of Hospital Disinfection
Supply Center
·Automatic control of PLC + touch screen , through the liquid level interlock, the equipment automatically opens
and stops to realize the unattended.
· With touch screen of interface,screen of dynamic process which make operation easier.
· With the functions of automatic flushing, automatic making water, protections of low pressure , no water , leakage
and overheating etc.
· With sound and light alarm functions of low pressure, low liquid level, excessive water quality, hot water overload,
leakage and others.
· With storage and consulting functions of operation parameters, sound and light alarm, consumables replacement
and other historical records.
· Multi-function monitoring to realize online displays of pressure, flow, conductivity and other parameters .
· With intelligent management of consumable life, reminder function of replacement function, which ensures the
water quality.
· The function of automatic flushing simplifies operation and prolongs the service life of the equipment
· The water system adopts frequency constant pressure technology, which makes the water supply more stable and
energy saving.
· The piping of the main engine is made of sanitary stainless steel to reduce the leakage rate
· The equipment consists of pretreatment system, two-stage reverse osmosis system and frequency transfer
sterilization system.
· Integrated structure of main machine and small floor area effectively save the space.
· The equipment has low energy consumption, long consumable life and low cost of producing water.
· Function of slow starting and stopping (optional) with high pressure pump of frequency conversion control
· Centralized display function (optional) of parameters touch screen of operation pressure, flowing volume, electrical
conductivity, liquid level of water
tank etc.
· Remote monitoring function (computer, mobile phone) (optional)
The pure water machine in the disinfection supply center fully meets the requirements of water quality, the touch screen is fully automatic controlled, and the medical pure water machine can be remotely operated by computer or mobile phone.
USAGE ENVIRONMENT OF MEDICAL PURE WATER MACHINE
Water quality in accordance with gb5749-2006 calibration water pressure 0.2-0.4mpa, Power source: 380V/50Hz three-phase five-wire system, reliable grounding environmental
temperature: 5-35ºC,Environmental degree: ≤ 80% RH, Installation site: the ground is flat and waterproof, with smooth drainage floor drain or drainage trench, no direct sunlight
Technical participation of medical pure water machine
The water quality of the water meets the requirements of the management standard of Hospital Disinfection Supply
Center (WS310.1-2016). Ion
removal rate: ≥99%, bacterial virus removal
rate: ≥99%, recovery rate: ≥60%
Features of medical pure water machine
· The quality of produced water shall comply with WS310.1-2016 Management Standard of Hospital Disinfection
Supply Center
·Automatic control of PLC + touch screen , through the liquid level interlock, the equipment automatically opens
and stops to realize the unattended.
· With touch screen of interface,screen of dynamic process which make operation easier.
· With the functions of automatic flushing, automatic making water, protections of low pressure , no water , leakage
and overheating etc.
· With sound and light alarm functions of low pressure, low liquid level, excessive water quality, hot water overload,
leakage and others.
· With storage and consulting functions of operation parameters, sound and light alarm, consumables replacement
and other historical records.
· Multi-function monitoring to realize online displays of pressure, flow, conductivity and other parameters .
· With intelligent management of consumable life, reminder function of replacement function, which ensures the
water quality.
· The function of automatic flushing simplifies operation and prolongs the service life of the equipment
· The water system adopts frequency constant pressure technology, which makes the water supply more stable and
energy saving.
· The piping of the main engine is made of sanitary stainless steel to reduce the leakage rate
· The equipment consists of pretreatment system, two-stage reverse osmosis system and frequency transfer
sterilization system.
· Integrated structure of main machine and small floor area effectively save the space.
· The equipment has low energy consumption, long consumable life and low cost of producing water.
· Function of slow starting and stopping (optional) with high pressure pump of frequency conversion control
· Centralized display function (optional) of parameters touch screen of operation pressure, flowing volume, electrical
conductivity, liquid level of water
tank etc.
· Remote monitoring function (computer, mobile phone) (optional)
| model | Water yield L/H(25C) | Host size(mm) | power(kw) | Installation site requirements Leakage In / out / out / Floor space protectio Pipe diameter | ||
| RS-250l | 250L/H | 1100*700*1650 | 2.5 | 10A | >25/25/32 | >6 |
| RS-500l | 500L/h | 1450*680*1700 | 3.0 | 10A | >25>25/32 | >8 |
| RS-1000l | 1000L/H | 1650*850*1700 | 3.5 | 16A | >32/32/40 | >10 |
| RS-2000l | 2000L/h | 1600*750*1650 | 5.5 | 25A | >40/32/50 | >12 |
| RS-250ll | 250L/H | 1500*750*1700 | 3.0 | 10A | >25/25/32 | >8 |
| RS-500ll | 500L/h | 1600*750*1650 | 4.5 | 10A | >32/25/40 | >8 |
| RS-1000ll | 1000L/H | 1600*750*1650 | 5.5 | 25A | >40/32/50 | >12 |
| RS-2000ll | 2000L/H | 2000*900*1650 | 8.0 | 32A | >50/32/63 | >18 |
